D94ABC0N0B

Product is no longer available

More information and services related to this product

1 / 0
Photo Nr. 1 of the product D94ABC0N0B
Photo Nr. 2 of the product D94ABC0N0B
Photo Nr. 3 of the product D94ABC0N0B
Photo Nr. 4 of the product D94ABC0N0B
Photo Nr. 5 of the product D94ABC0N0B
Photo Nr. 6 of the product D94ABC0N0B
D94ABC0N0B

Product is no longer available

More information and services related to this product

D94ABC0N0B

Product is no longer available

More information and services related to this product

Technical Overview

Installation typology
Wall-mounted
Type of appliance width
90 cm
Control your hood with your Home Connect hob
No
Sound pressure recirculated air level 2
55 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
613 m³/h

Highlights

Specifications

Type of appliance width
90 cm
Color body
Stainless steel
Installation typology
Wall-mounted
Operating Mode
Convertible
Total power of the motors
215 W
Number of speed settings
3
Maximum output air extraction
613 m³/h
Sound power at max. speed (2010/30/EC)
69 dB
Maximum output recirculating air
422 m³/h
Sound power at max. speed (recirculation)
74 dB
Grease filter material
Washable aluminium
Energy efficiency rating
B
Total annual energy consumption
46.2 kWh/annum
Included user manuals
[EN]
Height of the appliance
50 mm
Width of the appliance
900 mm
Depth
488 mm
Dimensions of the packed product (HxWxD)
490x650x1030 mm
Height of the chimney
576-897/576-1007 mm
Minimum distance above an electric hob
550 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
15.6 kg
Handle bar
Not applicable
Appliance height exhaust air max
947 mm
Appliance height exhaust air min
617 mm
Appliance height recirculating max
1057 mm
Appliance height recirculating min
617 mm
1 / 0
Photo Nr. 1 of the product
Photo Nr. 2 of the product
Photo Nr. 3 of the product
Photo Nr. 4 of the product
Photo Nr. 5 of the product
climatecontrol sensor
No
SilentPowerDrive
No
Silence
No
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
LED
Number of lights
2
Total luminance
101 lux
Colour temperature
Neutral (3.500 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
