Datasheet
Datasheet
Technical Overview
Dimensions
717x594x550 mm
Integrated Cleaning system
No
Range of temperature
50-275 °C
Cooking method
Full width grill, Hotair gentle, Hot Air, Conventional heat, Pizza setting, Hot air grilling
Cooking method second cavity
Full width grill, Half width grill, Conventional heat, Bottom heat
Plug type
no plug (electrical connection by electrician), fixed connection (electrical connection by electrician)
Home Connect Footnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Highlights
Specifications
Colour of appliance
Stainless steel
Display control
White LCD display with knob control
Number of heating & combination modes
6
Cooking method
Full width grill, Hotair gentle, Hot Air, Conventional heat, Pizza setting, Hot air grilling
Cooking method second cavity
Full width grill, Half width grill, Conventional heat, Bottom heat
Range of temperature
50-275 °C
Steam technology
N/A
Integrated Cleaning system
No
Door hinge
Drop down
Usable volume (of cavity) - NEW (2010/30/EC)
47 l
Usable volume (of cavity) - cavity 2
34 l
Energy efficiency rating
A
Energy efficiency class (2010/30/EC) - cavity 2
B
Safety device
Child-proof lock
Included accessories
2 x combination grid, 1 x universal pan
Dimensions
717x594x550 mm
Dimensions of the packed product (HxWxD)
790x660x690 mm
Minimum height for installation
720 mm
Maximum height for installation
720 mm
Minimum width for installation
560 mm
Maximum width for installation
560 mm
Depth for installation
550 mm
Net weight
47.2 kg
1 / 0
Plug type
no plug (electrical connection by electrician), fixed connection (electrical connection by electrician)
Connecting cable type
1-phase, neutral conductor
Voltage
220-240 V
Connection Rating
5300 W
Fuse protection
25 A
Included user manuals
[EN]
cookm coolstart
No
Less time needed for preheating
Yes
Pizza setting
Yes
Sensors
N/A
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
