N 70 Wall-mounted cooker hood 90 cm Matt blackD97BDN2S0B
D97BDN2S0B
Quiet Model
1 / 0
N 70 Wall-mounted cooker hood 90 cm Matt blackD97BDN2S0B
D97BDN2S0B
Datasheet
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power.
N 70 Wall-mounted cooker hood 90 cm Matt blackD97BDN2S0B
D97BDN2S0B
Datasheet
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power.
Technical Overview
Installation typology
Wall-mounted
Type of appliance width
90 cm
Control your hood with your Home Connect hob
Yes
Noise level
56 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
399 m³/h
Boost position air extraction
699 m³/h
Awards
Specifications
Type of appliance width
90 cm
Color body
Matt black
Installation typology
Wall-mounted
Operating Mode
Convertible
Total power of the motors
105 W
Type of control setting devices
Touch control, Via app
Number of speed settings
3-stages + intensive setting
Maximum output air extraction
399 m³/h
Boost position air extraction
699 m³/h
Sound power at max. speed (2010/30/EC)
56 dB
Sound power boost (2010/30/EC)
68 dB
Maximum output recirculating air
410 m³/h
Boost position output recirculating
677.0 m³/h
Sound power at max. speed (recirculation)
64 dB
Sound power boost (recirculation)
73 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
A++
Total annual energy consumption
24.5 kWh/a
Included user manuals
[EN]
Voltage
220-240 V
Height of the appliance
60 mm
Width of the appliance
898 mm
Depth
500 mm
Dimensions of the packed product (HxWxD)
700x580x1020 mm
Height of the chimney
GENERAL.N_A mm
Minimum distance above an electric hob
550 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
16.9 kg
Handle bar
N/A
Appliance height exhaust air max
895 mm
Appliance height exhaust air min
635 mm
Appliance height recirculating max
1080 mm
Appliance height recirculating min
803 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
Yes
Silence
Yes
Clean filter reminders
No
Boost position
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
GENERAL.N_A W
Total luminance
461 lux
Colour temperature
Neutral (3.500 K)
Illumination type softlight
Yes
Color temperature control via smartphone with Home Connect
Yes
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Home Connect Features
iService Remote, Remote Monitoring and Control
Control your hood with your Home Connect hob
Yes
Smart Hood Automatic
Yes, with all hobs with same feature and connected Home Connect account
