N 50 Integrated Design Hood 60 cm clear glass, Matt blackD65XCC2S0B
D65XCC2S0B
Quiet Model
1 / 0
N 50 Integrated Design Hood 60 cm clear glass, Matt blackD65XCC2S0B
D65XCC2S0B
Datasheet
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power.
N 50 Integrated Design Hood 60 cm clear glass, Matt blackD65XCC2S0B
D65XCC2S0B
Datasheet
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power.
Technical Overview
Installation typology
Built-in
Type of appliance width
60 cm
Control your hood with your Home Connect hob
No
Noise level
65 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
582 m³/h
Awards
Specifications
Type of appliance width
60 cm
Color body
Matt black
Installation typology
Built-in
Operating Mode
Convertible
Total power of the motors
185 W
Type of control setting devices
Button
Number of speed settings
3
Maximum output air extraction
582 m³/h
Sound power at max. speed (2010/30/EC)
65 dB
Maximum output recirculating air
521 m³/h
Sound power at max. speed (recirculation)
72 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
B
Total annual energy consumption
70.5 kWh/a
Included user manuals
[EN]
Voltage
220-240 V
Height of the appliance
60 mm
Width of the appliance
598 mm
Depth
298 mm
Dimensions of the packed product (HxWxD)
500x580x720 mm
Height of the chimney
GENERAL.N_A mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
7.7 kg
Handle bar
N/A
Appliance height exhaust air max
340 mm
Appliance height exhaust air min
340 mm
Appliance height recirculating max
340 mm
Appliance height recirculating min
340 mm
Maximum width for installation
560 mm
Minimum width for installation
560 mm
Depth for installation
300 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
No
Silence
No
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
GENERAL.N_A W
Total luminance
316 lux
Colour temperature
Neutral (3.500 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
