Technical Overview
Energy Efficiency Class Footnote 1: Scale of Energy Efficiency Classes from A to G
E
The water consumption of the eco programme in liters per cycle
9.5 l
Airborne acoustical noise emission class
B
Drying system
EcoDry - end of cycle door opening for perfect results, Heat exchanger
Home Connect Footnote 2: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
aquaStop
Yes
Highlights
Specifications
Installation typology
Full-integrated
Built-in / Free-standing
Built-in
Colour of appliance
N/A
Removable top
No
Variable hinge
No
Column installation
Yes
Adjustable plinth
Both horizontal and vertical
Energy Efficiency ClassFootnote 1: Scale of Energy Efficiency Classes from A to G
E
Energy Consumption for 100 cycles Eco ProgrammeFootnote 3: Energy consumption in kWh per 100 cycles (in programme Eco 50 °C)
76 kWh/100 cycles
The energy consumption of the eco programme in kWH per cycle
0.755 kWh/cycle
The water consumption of the eco programme in liters per cycle
9.5 l
Airborne acoustical noise emission class
B
Airborne acoustical noise emissions
44 dB(A) re 1 pW
Programme durationFootnote 4: Duration of programme Eco 50 °C
3:15 h
Maximum number of place settings
10
List of programmes
IntensivePlus, Auto 45-65°C, Economy, Glass, Quick wash 65ºC, Pre-rinse
Additional operational options
VarioSpeedPlus, Power Zone, Extra Dry, Machine Care
aquaStop
Yes
Drying system
EcoDry - end of cycle door opening for perfect results, Heat exchanger
rackmatic normal
Yes
Tub material
Stainless steel
3rd Rack
Flex 3 drawer
Cutlery system
Cutlery drawer
Number of Flip Tines in Upper Rack
3
Number of Flip Tines in Lower Rack
4
Anti-slip protection in the upper basket
No
Adjustable upper basket
Rackmatic 3-stage
Dimensions of the packed product (HxWxD)
880 x 510 x 670 mm
Net weight
33.3 kg
Depth with open door 90 degree
1150 mm
Minimum height for installation
815 mm
Maximum height for installation
875 mm
Minimum width for installation
450 mm
Maximum width for installation
458 mm
Depth for installation
550 mm
Weight furniture front (min - max)
2.5 - 7.5 kg
Height of removable worktop
0 mm
1 / 0
openassist
Yes
TFT display
No
Program status indication
Time light
Drying progress indicator
End of program audible
Start delay time max (h)
24 h
Precise Glass Protection
No
SilentPowerDrive
Yes
aquasensor
Yes
Water management system
No
Detergent detection
Yes
Home ConnectFootnote 2: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
aquaStop
Yes
Child safety devices
Yes
