Technical Overview
Installation typology
Wall-mounted
Type of appliance width
90 cm
Control your hood with your Home Connect hob
No
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
405 m³/h
Boost position air extraction
739 m³/h
Highlights
Specifications
Type of appliance width
90 cm
Color body
Black
Installation typology
Wall-mounted
Operating Mode
Convertible
Total power of the motors
140 W
Number of speed settings
3-stages + intensive setting
Maximum output air extraction
405 m³/h
Boost position air extraction
739 m³/h
Sound power at max. speed (2010/30/EC)
58 dB
Sound power boost (2010/30/EC)
71 dB
Maximum output recirculating air
249 m³/h
Boost position output recirculating
404 m³/h
Sound power at max. speed (recirculation)
62 dB
Sound power boost (recirculation)
72 dB
Grease filter material
Washable aluminium
Energy efficiency rating
A
Total annual energy consumption
39.0 kWh/a
Included user manuals
[EN]
Height of the appliance
430 mm
Width of the appliance
890 mm
Depth
362 mm
Dimensions of the packed product (HxWxD)
540x740x1040 mm
Minimum distance above an electric hob
450 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
22.7 kg
Handle bar
N/A
Appliance height exhaust air max
1251 mm
Appliance height exhaust air min
981 mm
Appliance height recirculating max
1311 mm
Appliance height recirculating min
1041 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
Yes
Silence
Yes
Clean filter reminders
No
Boost position
Yes
Delay Shut off modes
No
Remote control
No
Type of lamps used
LED
Number of lights
2
Total luminance
225 lux
Colour temperature
Neutral (3.500 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
