Technical Overview
Installation typology
Wall-mounted
Type of appliance width
60 cm
Control your hood with your Home Connect hob
No
Sound pressure recirculated air level 2
49 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
370 m³/h
Specifications
Type of appliance width
60 cm
Color body
Stainless steel
Installation typology
Wall-mounted
Operating Mode
Convertible
Total power of the motors
95 W
Type of control setting devices
Rocker switches
Number of speed settings
3
Maximum output air extraction
370 m³/h
Sound power at max. speed (2010/30/EC)
67 dB
Maximum output recirculating air
220 m³/h
Sound power at max. speed (recirculation)
67 dB
Grease filter material
Washable aluminium
Energy efficiency rating
E
Total annual energy consumption
94.3 kWh/a
Height of the appliance
246 mm
Width of the appliance
600 mm
Depth
500 mm
Dimensions of the packed product (HxWxD)
340 x 595 x 685 mm
Height of the chimney
553-730/573-730 mm
Minimum distance above an electric hob
550 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 / 120 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
11.1 kg
Handle bar
N/A
Appliance height exhaust air max
976 mm
Appliance height exhaust air min
799 mm
Appliance height recirculating max
976 mm
Appliance height recirculating min
799 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
No
Silence
No
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
Halogen
Number of lights
2
Total power of the lamps
60 W
Total luminance
270 lux
Colour temperature
Warm (<= 3.000 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
