Technical Overview
Installation typology
Built-in
Type of appliance width
75 cm
Control your hood with your Home Connect hob
No
Sound pressure recirculated air level 2
46 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
390 m³/h
Boost position air extraction
640 m³/h
Specifications
Type of appliance width
75 cm
Color body
Silver metallic
Installation typology
Built-in
Operating Mode
Convertible
Total power of the motors
200 W
Type of control setting devices
Slide switch
Number of speed settings
3-stages + intensive setting
Maximum output air extraction
390 m³/h
Boost position air extraction
640 m³/h
Sound power at max. speed (2010/30/EC)
59 dB
Sound power boost (2010/30/EC)
69 dB
Maximum output recirculating air
320 m³/h
Boost position output recirculating
430.0 m³/h
Sound power at max. speed (recirculation)
64 dB
Sound power boost (recirculation)
72 dB
Grease filter material
Washable aluminium
Energy efficiency rating
D
Total annual energy consumption
107.5 kWh/a
Height of the appliance
255 mm
Width of the appliance
730 mm
Depth
380 mm
Dimensions of the packed product (HxWxD)
290 x 790 x 440 mm
Minimum distance above an electric hob
650 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 / 120 mm
No-return airflow flap
No
Length electrical supply cord
130.0 cm
Net weight
10.0 kg
Handle bar
Not applicable
Appliance height exhaust air max
255 mm
Appliance height exhaust air min
255 mm
Appliance height recirculating max
255 mm
Appliance height recirculating min
255 mm
Maximum width for installation
700 mm
Minimum width for installation
700 mm
Depth for installation
350 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
No
Silence
Yes
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
Halogen
Number of lights
2
Total power of the lamps
40 W
Total luminance
345 lm
Colour temperature
Warm (<= 3.000 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
