Technical Overview
Installation typology
Built-under
Type of appliance width
60 cm
Control your hood with your Home Connect hob
No
Sound pressure recirculated air level 2
58 dB(A) re 1 pW
climatecontrol sensor
No
Operating Mode
Convertible
Maximum output air extraction
240 m³/h
Specifications
Type of appliance width
60 cm
Color body
Black
Installation typology
Built-under
Operating Mode
Convertible
Total power of the motors
125 W
Type of control setting devices
LED, Slide switch
Number of speed settings
3
Maximum output air extraction
240 m³/h
Sound power at max. speed (2010/30/EC)
71 dB
Maximum output recirculating air
80 m³/h
Sound power at max. speed (recirculation)
73 dB
Grease filter material
Not washable synthetic
Energy efficiency rating
E
Total annual energy consumption
91.3 kWh/a
Height of the appliance
150 mm
Width of the appliance
600 mm
Depth
482 mm
Dimensions of the packed product (HxWxD)
275 x 730 x 655 mm
Minimum distance above an electric hob
650 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
100 / 120 mm
No-return airflow flap
Yes
Length electrical supply cord
150.0 cm
Net weight
5.2 kg
Handle bar
Not applicable
Appliance height exhaust air max
150 mm
Appliance height exhaust air min
150 mm
Appliance height recirculating max
150 mm
Appliance height recirculating min
150 mm
1 / 0
climatecontrol sensor
No
SilentPowerDrive
No
Silence
No
Clean filter reminders
No
Boost position
No
Delay Shut off modes
No
Remote control
No
Type of lamps used
Halogen
Number of lights
1
Total power of the lamps
28 W
Total luminance
44 lm
Colour temperature
Warm (<= 3.000 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Control your hood with your Home Connect hob
No
Smart Hood Automatic
No
